Product Catalog
Precision-engineered gaskets for Tri-Clamp applications. Available in multiple materials and sizes to meet your specifications.
Find Your Perfect Gasket
Select the gasket type that matches your application requirements. All dimensions are approximate and meet industry standards.
Download Full Catalog
Select Gasket Type
Standard Tri-Clamp - Available Dimensions
| Size | Inner Diameter (ID) | Outer Diameter (OD) |
|---|---|---|
| 1/2" | 3/8" | 1" |
| 3/4" | 5/8" | 1" |
| 1" A | 15/16" | 1 1/4" |
| 1" | 7/8" | 2" |
| 1 1/2" | 1 3/8" | 2" |
| 2" | 1 7/8" | 2 1/2" |
| 2 1/2" | 2 3/8" | 3" |
| 3" | 2 7/8" | 3 1/2" |
| 4" | 3 7/8" | 4 1/2" |
| 5" | 4 3/4" | 5 1/2" |
| 6" | 5 3/4" | 6 1/2" |
Available Materials:
Available Materials
We offer a comprehensive range of rubber compounds and engineering plastics to meet your specific application requirements.
Nitrile Butadiene Rubber
Oil and fuel resistance
Ethylene Propylene Diene Monomer
Ozone, weather, and high temperature resistance
Fluoroelastomer
Superior chemical resistance, high temperature
Silicone Rubber
Extreme temperature flexibility
Neoprene/Chloroprene
Balanced properties for general purpose applications
Perfluoroelastomer
Ultimate chemical resistance for extreme applications
Rubber Compounds
Our rubber compounds are selected for their specific resistance properties, temperature ranges, and application suitability. All materials meet or exceed industry standards for sealing applications.
Need a Custom Solution?
We manufacture components to your exact specifications. Contact us to discuss your material and design requirements.
Request Custom Quote
